Solarius - 3D Metrology - Atlas


Solarius - 3D Metrology - Atlas

EASE OF USE and RELIABILITY make Atlas a remarkable tool for FAST and ACCURATE surface measurement

The Atlas 3D metrology tool is a modular surface measurement system for quality assurance and process control. Depending on specific needs, different types of 3D sensor technologies can be configured, making it a flexibel tool that allows accurate results at a broad variety of 3D measuring requirements, materials and geometries. Its software supports automation and efficiency in a production environment. Interferometric 3D sensors allow high speed measurements with up to 80,000 points in as few as 130 milliseconds at lateral resolutions down to 4 µm.

Key Features:

  • Customized recipes, easy to automate
  • Ultra-fast measurements
  • Wide variety of sensor selections
  • Large lateral measurement range
  • Flexible data analysis tools

Sensor Types:

  • Chromatic confocal point sensors
  • Chromatic confocal line sensors
  • White light interferometric sensors
  • Line triangulation sensors

Using sensors with point confocal, line confocal, interferometric or line triangulation technology, its height resolution ranges from 1 nm to 200 µm. The Atlas software solution combines two software tools: a measurement recipe creation tool and a flexible analysis tool. This unique combination is ideal for applications in research and development, failure analysis, and low-volume semi-automated measurement.

Lateral Working Range

up to 400 mm x 400 mm

Vertical Working Range

100 µm to 80 mm

Lateral Resolution

1 µm up

Vertical Resolution

1 nm up


For further details, please refer to enclosed brochure.

Solarius is a leading provider of precision systems for non-contact surface inspection, measurement, analysis, and visualization. Our products combine high-resolution sensors with automated data acquisition systems and powerful analysis tools.  Augmented by our international partner network Solarius takes care of an installed base exceeding 2,000 active metrology systems worldwide.
