AMADA - Advanced Data Analysis Monitor - WM-100A
With an ever-increasing emphasis on accountability, AMADA WELD TECH’s WM-100A is the most advanced resistance welding monitoring system available from any manufacturer. Built in the USA, the WM-100A offers more of the information you need for resistance welding process development, production monitoring and data to support your ISO, and GMP and TQM requirements. Not only will it monitor what happens during the weld, but also before it is triggered, giving you a true 360-degree view of your welding process.
Key features
Advanced Data Analysis Monitor WM-100A
360º view of your weld including pre- and post- weld data
Measure current, voltage, force, displacement and cover gas flow/auxiliary input
Production run screen with run charts, histogram and process results
High resolution sensors
Simple user-interface includes large color display
Monitor ANY Resistance Welder
TCP/IP Communications Enabled
| Feature | Benefit |
| Current, voltage, power, resistance monitoring | Detects shifts in welding process |
| High resolution displacement monitor with part detection | Improved process control |
| Force or pressure monitor | Ensures welding at proper electrode force |
| Cover gas flow monitor | Confirms displacement of oxygen from weld area |
| Pretrigger viewing | Captures important pre-weld data |
| Envelope limits | Catches slight changes in waveform shapes |
| Numeric limits | Evaluates peak and RMS data |
| Graphical waveforms with cursors | Interrogates waveforms for better
understanding of process |
| Multi Level security screens | Protects settings from unauthorized changes |
| Comprehensive I/O for automation | Easily integrated into automated systems |
| Wide screen color display | Easy to view settings and process results |
| Multiple schedules with schedule naming | Customized schedules for ease of use |
| Traceability to NIST standards | Meets regulatory guidelines |
| Ethernet communications | Remote reading of database |
| Weld to displacement | Improves process control |
Technical Specifications
Input power | 100 - 240 VAC |
|---|
Built-in printer | No |
|---|
Automation ready | Yes |
|---|
Waveform analysis | Yes |
|---|
Limit types | Peak
RMS
Envelope |
|---|
Measurable parameters (range) | Current (2, 6, 20, 60, 200 kA)
Voltage: (0 - 15 V)
Displacement (12, 25, 30 mm)
Force
Gas flow / auxiliary (0 - 10 V) |
|---|
Size (L x W x H) | 15.35 in x 16.81 in x 6.96 in (390.0 mm x 427.0 mm x 176.8 mm) Data Processing Module (not including handles)
13 in x 4.9 in x 10.75 in (330 mm x 125 mm x 273 mm) Sensor Interface Module
9 in x 21 in x 17 in (229 mm x 533 mm x 432 mm) Monitor (size may vary) |
|---|
Weight | 17.5 lb (8 kg) Data Processing Module
11.5 lb (5.3 kg) Sensor Interface Module
10 lb (4.5 kg) Monitor (weight may vary with size) |
|---|
AMADA WELD TECH is part of the Amada group and known as an innovator in finding creative joining and metal processing solutions.
AMADA WELD TECH is the market leader in developing, building and servicing systems, machines and components for Laser Welding, Laser Marking, Laser Cutting & Processing, Resistance Welding, Hot Bar Bonding, Micro Arc Welding, and Hermetic Sealing. We design and manufacture industry-leading product families for the global market. These product families include OP-AWS3-A, EZ-Air, Jupiter, Markermotion, NH Series, UF Series and Weld Checker. Our legacy brands MIYACHI UNITEK, MIYACHI PECO, MIYACHI EAPRO and MACGREGOR will be united into one brand: “MIYACHI”.
