AMADA - DC Inverter Welding Power Supply, IS-800A/1400A
Key Features
Pulse limit control and Voltage compensation feature enable detailed parameter settings.
Ground fault and short-circuit protections ensure the safety better.
Adjustable welding frequency from 600 to 3000kHz with 100Hz increment.
Program protect feature prevents false operation due to unintended touches to the screen.
Up to the third welding is controllable. Pulsation and other control modes can be set for each welding.
The analog output terminal (voltage output proportional to force) for force control with electro-pneumatic proportional valve and the analog input terminal (voltage input proportional to force) for force measurement have two channels, respectively.(Only IS-800A/1400A-20)
Welding can be stopped at the set displacement by connecting the displacement gauge and measuring the displacement produced in fusing. (Only IS-800A/1400A-20)
Technical Specifications
Model | IS-800A | IS-1400A |
Power requirements | ・Three phase, 380-480VAC (50/60Hz)10%
・Three phase, 200-240VAC (50/60Hz)10% | ・Three phase, 380-480VAC (50/60Hz)10%
・Three phase, 200-240VAC (50/60Hz)10% |
Maximum output current | 800A (3%) | 1400A (3%) |
Number of schedules | 255 | Number of schedules |
Output frequency | 600Hz～3kHz | Output frequency |
Control method | Primary current RMS/ Secondary current RMS/ Secondary power RMS/ Primary current PEAK/ Secondary voltage RMS/ Constant phase | Primary current RMS/ Secondary current RMS/ Secondary power RMS/ Primary current PEAK/ Secondary voltage RMS/ Constant phase |
Current monitor | HIGH 0.00～9.99kA / LOW 0.00～9.99kA | HIGH 00.0～99.9kA / LOW 00.0～99.9kA |
Power monitor | HIGH 0.00～9.99kW / LOW 0.00～9.99kW | HIGH 00.0～99.9kW / LOW 00.0～99.9kW |
