Nutek - Conveyor - In-line Workstation - NTA Series
The NTA In-line Workstation is used to link between SMD machines or board handling units. It also allows manual assembly work to be carried out.
Key Features
- 4.3” touchscreen panel
- Modular design
- Stability enhanced by ‘robust design’
- Laser carved stainless steel side guides for superior quality and durability
- PCB inspection mode provided
- Servo motor controlled width adjustment
- Different lengths available upon request
- Multi-zone concept available upon request
- Equipped with lighting features, single layer part tray and foot rest
- Equipped with ESD scallop table and ESD bracelet connection
- Variable speed control
- Patented (SG Patent No.: 91261)
- Programmable product setting
- Industry 4.0 ready
- OPC UA ready
- CANOpen communication ready
Technical Specifications
Conveyor Concept | Belt |
---|
Conveyor Speed | 0.5 - 14 m/min. or specify |
---|
Conveyor Length | 1000 mm or specify |
---|
Power Source | 100, 230VAC 1Ph |
---|
Power Consumption | 200VA max. |
---|
Available Models
Model No. | Size | Machine Dimension (mm) L x W x H | Fixed Point to Front Dimension (X) | Weight (Approximately) |
---|
NTM1800-M | M | 1000 x 887 x 2190 | 438 mm | 110 kg |
---|
NTM1800-L | L | 1000 x 1044 x 2190 | 438 mm | 120 kg |
---|
